Company Advantages1. All types of contaminants can be removed by excellent water treatment system. Owing to its various quality attributes, provided
edi water system is highly appreciated by Ocpuritech clients.
2. Guangzhou Aomi
Water Purification System Manufacture Co., Ltd.'s customer service always works on a professional level. Water Treatment System can be very easy to maintain
3. Guangzhou Aomi Water Purification System Manufacture Co., Ltd. has put more advanced features into electrodeionization to make it more attractive. Easy operation is one of the features Ocpuritech products enjoy
EDI Stack Inlet Requirements
Capacity | 300lph-50000lph |
Control type | Micro controller/PLC
( touch screen option） |
Recovery rate | ≥90% |
Total exchange anions
(mg/L,as CaCO3) | ≤35 |
Total hardness
(mg/L,as CaCO3) | ≤1 |
TOC(mg/L) | ≤0.5 |
Residual chlorine(mg/L) | ≤0.02 |
Oxidizing agent | 0 |
Silicon dioxide(mg/L) | ≤0.5 |
SDI15 | ＜1 |
PH | 7-9 |
TMP(℃) | 5-35 |
Variable valency metal(mg/L) | Fe≤0.01 Mn≤0.01 |
Pressure(bar) | ≤4 |
EDI,CEDI(Electro-deionization) is a process that uses ion exchange resins to absorb ions from a dilute water stream and then transports the absorbed ions through ion-exchange
membranes into a concentrate water stream under the influence of an applied electro field. In the process，ion exchange resins do not need to be regenerated
via acid or alkali. This new technology could replace traditional Electrode ionization (DI) equipment, produces ultrapure water whose resistance can reach 18 MΩ·cm
Based on your raw water quality and produced water requirements ,it can all be fully customized and designed by our professional engineers to meet your business requirements.
Typical Applications
A mixed bed ion exchange unit has to be regenerated by using acid and alkali, but an EDI system does not need to be involved in such a process. This is the fundamental advantage of EDI technology over the conventional ion exchange technology. Furthermore, this advantage can be expressed into other aspects as listed below.
1.EDI process does not consume regeneration chemicals.
2.EDI process does not create waste water and is much more environmental-friendly.
3.
EDI systems do not require shutdown for regeneration.
4.EDI systems are smaller than mix bed ion exchange units.
5.EDI process provides water with consistent quality.
6.Operating expenses are lower than that of ion exchange units.
Pharmaceutical and bio-medical industries
Steam Generation / Boiler Feed /Microelectronics / Semiconductor /makeup use water
Surface finishing /Chemical manufacturing
Company Features1. Ocpuritech specializes in manufacturing electrodeionization with high quality and reasonable price. - Adversity Successfully Overcome Is The Highest Glory. Ocpuritech Offers A Wide Range Of edi system, edi water system, edi water treatment At Reasonable Price To Customers From All Over The World. Please Contact Us!
2. electrodeionization is the life of an enterprise which needs the full concentration and meticulous of employees during the work.
3. Guangzhou Aomi Water Purification System Manufacture Co., Ltd. has solidified and advanced its edi system production ability with modern technology. - Ocpuritech focuses on continuous technological innovation to improve products and services. Call!
