Guangzhou 30TPH Ro water plant drinking water plant / design water purification methods
Product name ------------ 30TPH large scale reverse osmosis water purification system
Operation capacity ------30T/H
RO water treatment technology is the most advanced and energy-saving membrane separation technology. Water pressure (higher than the osmotic pressure of the solution) is used to force water molecules go through a very fine membrane, leaving the contaminants behind. Ro system can remove salt and most of the organisms and microorganisms which exist in the water (removal can reach 97%-98%).
30TPH large scale reverse osmosis water purification system details
Raw water pump
Control panel,touch screen
(Double door explosion proof control box,VFD inside)
8040-5 elements FRP Housing
1. Electronic industry: Pre-filter for ultra pure water, chemical products and pure water
2. Food and beverage industry: filter for mineral water, wines and fruit juice, bottled drinking water
3. Medicine industry: filter for drug liquid
4. Chemical industry: filter for organic solvent
5. Petroleum industry: filter for oil-field flooding
1.System can produce water continuously, PLC program controlled, Simple in installation and operation
2. RO system be chosen the import USA DOW membrane
3. Tank level control, automatic stop when the raw water tank without water or pure water tank is full
4. RO system flushes RO membranes when it starts to work so that membrane fouling is reduced.
5. Nanfang(CNP) high pressure pumps or Denmark Grundfos high pressure pumps are adopted.
6. Product water quality is continuously monitored by conductivity meter.
System technical parameter table
Guangzhou Aomi Water Purification System Manufacture Co., Ltd. is one of the Professional Manufacturers for Water Treatment Equipments in China since many years ago. We have the expertise to manufacture water treatment equipments (RO, UF, EDI, RO+EDI, RO+MIXED BED) of different sizes, capacity and optional functions. And we also provide relative products such as FRP tank, valves, filter cartridge and membranes etc.
Our water treatment products have been used in many countries around the world and we'll try our best to serve for you.
2, Western Union;
1)We're 24 hours online.
2)The product has one year warranty.
3)English Installation Instruction.
Our Customers culture
Q: What is Reverse Osmosis?
A: Reverse osmosis (R/O) is a water treatment process in which water is forced through a semi-permeable membrane that has very small holes or "pores". Clean water passes through and impurities that are too big to pass through the membrane are left behind and flushed away.
Q: How Does Reverse Osmosis Work?
A: Reverse osmosis systems purify water by forcing pressurized water through a very fine, plastic membrane. If the raw water being treated comes from a well or another private source, disinfection and pre-filters (to remove chlorine and/or particulates/sediment) may be needed in advance of the R/O unit to remove contaminants that can foul or damage the membrane.
Q: How Do I Know What Size Unit to Buy?
A: R/O units are rated according to the amount of treated water produced per day. For example, one type of unit produces 5000 liters of treated water per day under its design conditions. In reality, conditions frequently vary. Line pressure is often lower, water will frequently be colder than 25° C and backpressure in the storage tank will likely reduce the performance of the unit. Consequently, you should examine water conditions and buy a larger rated unit than needed if any of the above problems are noted
Q: Material of reverse osmosis system?
A: You can choose FRP filter + U-PVC pipe, stainless steel filter + U-PVC pipe or total stainless steel.
Q: What is packing of this machine? Is it suitable for shipment?
A: Machine will be packed by standard wooden case. It is suitable for shipment. After you receive machine, you only need to open wooden case to pick up machine.
Q: Is this machine easy to install? Will you arrange engineer to help me install?
A: This machine is very easy for install. The machine you received is assembled. You will only need to put material inside to filters, and then backwash, fast rinse filters. It is very easy for you to follow our English instruction and video.
Q: How can I pay you?
A: After we confirmed order, I will send you contract sales with our company bank information. You can transfer money to our company bank account by T/T.
Guidlines for getting a proper quotation:
1.Tell us the production capability you want(500L/H,1000L/H......)?
2.What is your source water(tap water/underground water....)?
3.What is the product water used for(drinking /bottled water....)?
